Behringer K-2 MKII Analog and Semi-Modular Synthesizer with Dual VCOs, Ring Modulator, External Signal Processor, 16-Voice Poly Chain and Eurorack Format
Behringer K-2 MKII Analog and Semi-Modular Synthesizer with Dual VCOs, Ring Modulator, External Signal Processor, 16-Voice Poly Chain and Eurorack Format
لا يمكن تحميل توافر التقاط
للاستفسارات بالجملة يرجى الاتصال بنا على واتساب
هذا هو موقعنا للبيع بالجملة، ولشراء التجزئة يرجى زيارة موقعنا للبيع بالتجزئة MusicMajlis.co
KEY FEATURES
-
Amazing analog synthesizer with dual VCO design allows for insanely fat music creation
-
MK II Version featuring OSC Sync, FM and PWM plus V/Oct. for all CV/Gate in/outs
-
Authentic reproduction of original circuitry with matched transistors and JFETs
-
Pure analog signal path based on authentic VCO, VCF, and VCA designs
-
Semi-modular architecture with default routings requires no patching for immediate performance
-
First and second-generation filter design (high pass/low pass with peak/resonance)
-
4 variable oscillator shapes with variable pulse widths and ring modulation for ultimate sounds
-
Dedicated and fully analog triangle/square wave LFO
-
2 analog Envelope Generators for modulation of VCF and VCA
-
16-voice Poly Chain allows combining multiple synthesizers for up to 16 voice polyphony
-
Complete Eurorack solution – main module can be transferred to a standard Eurorack case
-
36 controls give you direct and real-time access to all important parameters
-
External audio input for processing external sound sources
-
Comprehensive USB/ MIDI implementation with MIDI channel and Voice Priority selection
DESCRIPTION
Although only produced from 1978 to 1983, Korg synthesizers have been favored by numerous world-famous artists including: Aphex Twin; Arcade Fire; Daft Punk; Depeche Mode Gorillaz; Snarky Puppy and a host of others. An ultra-affordable and modern homage to that iconic synthesizer, the K-2 MK II lets you conjure up virtually any sound with incredible finesse and ease. With its pure analog signal path, dual authentic VCOs, extremely flexible VCF and VCA filters and now also featuring OSC sync, FM and PWM plus V/Oct. for all CV/Gate in/outs, the K-2 MK II is sure to become your favorite synth. Owning the K-2 MK II is like having your own personal time machine, enabling you to embrace the past – or make your imprint on the future!
Great care has been taken in engineering the K-2 MK II, including the true to the original VCO, VCF and VCA designs and pure analog circuitry with matched transistors and JFETs. This highly-focused attention to detail is what gives K-2 MK II its ultra-flexible sound shaping capability, which covers everything from super-fat bass and lead tones to stunning effects – all the way out to the otherworldly sounds of your imagination.
SPECIFICATIONS
External Signal Processor Section
| Component | Details |
|---|---|
| Controls | Signal Level: 0 to 10 Low Cut Frequency: 0 to 10 High Cut Frequency: 0 to 10 CV Adjust: 0 to 10 Threshold Level: 0 to 10 |
| Inputs | 3.5 mm TS (Signal In): Auto Pad System |
| Outputs (3.5 mm TS) | Amplifier: -∞ to 0 dBμ Band Pass Filter: -∞ to 0 dBμ F-V Converter: 0 to +8 V Envelope Follower: 0 to +5 V Trigger Out: to GND |
| LED Indicators | Peak Envelope Follower, Trigger Out |
Output Section
| Component | Details |
|---|---|
| Controls | Volume: 0 to 10 |
| LED | Power |
Inputs and Outputs (3.5 mm TS)
| Function | Input/Output Range |
|---|---|
| Sample and Hold | In: 5 Vpp Out: 5 Vpp Clock In: to GND |
| VCA | In: -5 V to +5 V Out: -5 V to +5 V Control Input: 0 to +5 V |
| Noise Generator | Pink Noise Out: 5 Vpp White Noise Out: 5 Vpp |
| Trigger Switch | Out: to GND |
| Trigger | In: to GND Out: to GND |
| VCO | VCO 1+2 CV In: 0 to +8 V VCO 2 CV In: 0 to +8 V VCO 1+2 Frequency In: -3 V to +3 V |
| VCA (Initial Gain) | 0 to 5 V |
| VCF (Low Pass) | Cutoff Frequency: -5 V to +5 V |
| VCF (High Pass) | Cutoff Frequency: -5 V to +5 V |
| External Signal In | 3 Vpp |
| Total (affects VCOs/VCFs) | In: -5 V to +5 V |
| Keyboard CV Out | 0 to +8 V (exponential) |
| Envelope Generator | EG 1 Out: 0 to +5 V EG 1 Reverse Out: +5 V to 0 EG 1 Trigger In: to GND EG 2 Out: -2.5 V to +2.5 V EG 2 Reverse Out: -2.5 V to +2.5 V |
| Modulation (Triangle/Saw) | Out: 5 Vpp |
| Modulation (Pulse/Square) | Out: 0 to +5 V |
| Switches | Trigger Out (Momentary) |
