Authorised Distributor

Behringer CP3A-M MIXER

SKU: CP3A-M MIXER
Regular price 396.00 AED

List price. Trade accounts get better pricing: ask us for a B2B quote. Contact us

Out of stock
Available on request
  • Full Specifications

    Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information

    KEY FEATURES
    • Vintage-sounding CP3A-M Mixer module from the '70s

    • Authentic reproduction of the circuitry from the "Modular 55, 35 & 15" Series

    • Artist roster includes world's most famous pop, rock and jazz musicians

    • Module features 4 input channels with separate controls and 2 sets of 2 outputs

    • Master Gain for overall control of output volumes

    • Dual 4-point multiple circuit for flexible patching

    • 5 controls give you real-time access to all important parameters

    • Eurorack specs: 14 HP, 30 mA +12 V, 30 mA -12 V


    DESCRIPTION

    The first System 55, 35 and 15 synth modules came out in the early 70s and tended to be extremely expensive. They were mainly all discrete transistor designs as op-amps at the time were very high cost. The discrete circuitry gave the modules a very distinctive sound and were used by artists like Keith Emerson, Stevie Wonder, Tangerine Dream and so many more, giving us some of the greatest records we’ve ever heard. Modular synths were a landmark development in electronic music and today, it’s about to get better.

    SPECIFICATIONS

    Controls

    Channel gain

    4 x rotary knob

    Maximum input level

    +14 dBu

    Master gain

    1 x rotary knob

    Maximum output level

    +14 dBu

    Signal Connections

    Inputs

    4 x 3.5 mm TS jack, mono

    Impedance

    10 kΩ unbalanced

    Multiple

    8 x 3.5 mm TS jack, mono

    Arrangement

    2 sets of 4 parallel jacks, passive

    Compatibility

    CV and audio signals

    Outputs

    4 x 3.5 mm TS jack, mono

    Impedance

    220 Ω to 5 kΩ, unbalanced

    Output noise

    < -85 dBu, 22 Hz - 22 kHz

    Power

    Power supply

    Eurorack

    Current draw

    30 mA (+12 V), 30 mA (-12 V)

    Physical

    Dimensions (H x W x D)

    129 x 71 x 35 mm (5.1 x 2.8 x 1.4")

    Rack units

    14 HP

    Weight

    0.16 kg (0.35 lbs)
