Home / Behringer RD6SR Classic Analog Drum Machine
Behringer RD6SR Classic Analog Drum Machine
Behringer RD6SR Classic Analog Drum Machine
Behringer RD6SR Classic Analog Drum Machine
Behringer RD6SR Classic Analog Drum Machine
Behringer
Authorised Distributor

Behringer RD6SR Classic Analog Drum Machine

SKU: RD6SR

Log in to view price Trade pricing — AED / USD

Only 2 left
Low inventory - Hurry up!
Request Bulk Pricing

Ask an AV specialist

Video chat Chat Email +971 50 559 4871

  • Full Specifications

    Classic Analog Drum Machine with 8 Drum Sounds, 16-Step Sequencer and Distortion Effects

    Features:

    • Amazing Drum Machine with true analog circuitry for classic sound performance

    • Authentic reproduction of original circuitry with matched transistors

    • 8 original drum sounds with mix parameters and global accent capability

    • Highly acclaimed and authentic clap sound from the DR-110 drum machine

    • 6 independent analog outputs for external processing or recording your rhythms as multi-track audio

    • Easy-to-use 16-step drum sequencer with real-time switching between 32 separate patterns

    • Patterns can be chained into full songs with up to 250 bars

    • Distortion circuitry modeled after the RAT* adds insane spice and edge to your sounds

    • 16 authentic-style step buttons with LED indicators for easy pattern creation

    • 11 controls and 26 switches to give you direct and real-time access to all important parameters

    • MIDI and USB implementation for synchronization and connection to external devices

    • Sync options include USB, MIDI, Clock and Internal for maximum versatility



    Number of sounds 8
    Type Analog
    Number of simultaneous voices 8
    Power input DC input connector
    Power switch Push button on/off
    USB (MIDI) USB 2.0, type B
    MIDI In, Out / Thru 2 x 5-pin DIN
    Start / stop 1 x 1/4" TS
    Mix out 1 x 1/4" TS, unbalanced, 1 kΩ impedance
    Voice out 6 x 1/8" TS, unbalanced, 100 Ω impedance
    Sync in / out 2 x 1/8" TRS (Tip is clock and Ring is the start message) more than: 2.5 V
    Trigger outs LT and HT 2 x +15 V, 1PPS/24PPQ/48PPQ 50% pulse length, 2PPQ narrow pulse length.
    Phones 1 x 1/8" TRS, stereo, 15 Ω impedance
