Authentic Wavetable generators and analog VCF and VCA designs based on the PPG* Wave 2.2 and 2.3 from the ’80s
Classic digital wavetable synthesis with 8 or 16-bit resolution
Authentic analog signal path based on original VCF and VCA designs
8 voices configurable in modes such as splits, layers, and unison
30 classic factory wavetables and 64 user-defined wavetables, each comprising 64 waveforms, along with 32 user-defined transients
Easy import of user wavetables and transients through SynthTribe
200 user presets with storable sequence
Authentic and advanced oscillator modes for versatile sound design
Manual wavetable control for precise navigation through selected table waves with optional crossfading
Two ADSR envelopes for shaping the filter, amplifier, or wavetable position
Additional AD envelope for oscillator pitch modulation or wavetable position control
LFO for creating vibrato, tremolo, or cyclic wavetable sweeps
Built-in polyphonic sequencer optimized for both performance and studio applications
Dual arpeggiator with play modes including up, down, up-down, and random
49 full-size keys featuring velocity, aftertouch and polyphonic portamento for expressive playability
Stereo width control for dynamic voice placement within the stereo field
Individual audio outputs for all 8 voices to enable external processing per voice
CV/Gate and Sync In/Out connectivity for seamless integration with external gear
Expression and sustain pedal support for enhanced performance options
Comprehensive MIDI implementation for full integration and flexibility
Another legend of 80s music is here and it's sure to make its way into your collection. It’s time to ride the Behringer WAVE! Capable of classic 8 or 16-bit resolution wavetable synthesis plus up to 8 configurable voices, the sound of WAVE is synonymous with the sound of the 80s as artists like David Bowie, Jean Michel Jarre and Tangerine Dream, to name a few, used the original to create hits that still resonate today!
WAVE is amazing for creating lush pads, bass and even some bell- or chime-like sounds and that’s all thanks to its 8 highly configurable voices and its classic wavetables with 64 waves each, complemented by and additional 64 fixed sub-oscillator waveforms for added depth. Want to change the characteristics of a wavetable? The 2 ADSR envelopes allow you to sculpt your wavetable just the way you want it. There’s also a dedicated sub-oscillator position control for some extra nuance. And if you wanted to get even more sounds out of WAVE, additional user wavetables and transients can be easily imported via the SynthTribe app, available on both macOS and Windows.
WAVE’s 49 full-size keys, offer the perfect balance between expressiveness and playability. Aftertouch and velocity sensitivity, allow you to shape and modulate your sounds depending on how hard or soft you play.
| Category | Parameter | Details |
|---|---|---|
| Synthesizer Architecture | Type | Hybrid |
| Number of Voices | 8 | |
| Type of Oscillators | Wavetable | |
| Number of Oscillators | 16 | |
| Filter | 24 dB Lowpass | |
| Connectivity | USB (MIDI) | USB 2.0, Type B |
| MIDI In/Out/Thru | 5-pin DIN, 16 channels | |
| Main Output | 2 x 6.35 mm (1/4") TS, unbalanced, max. +22 dBu | |
| Main Output Impedance | 50 Ω | |
| Channel Out | 8 x 6.35 mm (1/4") TS, unbalanced, max. +22 dBu | |
| Headphones | 1/4" TRS, stereo, max 25 mW | |
| Headphone Impedance | 8 Ω | |
| Sync In | 6.35 mm (1/4") TRS | |
| Sync Out | 6.35 mm (1/4") TRS | |
| CV In | 6.35 mm (1/4") TS | |
| Gate In | 6.35 mm (1/4") TS | |
| Expression Pedal | 6.35 mm (1/4") TRS – voltage send on tip | |
| Sustain Pedal | 6.35 mm (1/4") TS | |
| USB | Type | Class compliant USB 2.0, Type B |
| Supported OS | Windows 7+ / macOS X 10.10+ | |
| Keyboard & Controls | Keyboard | 49 semi-weighted, full-size keys with velocity & aftertouch |
| Wheels | Pitch, Modulation | |
| Controls | Octave Down / Up | |
| LED | Octave -2 / -1 / 0 / 1 | |
| Volume Section | Controls | Basis (Mono to Stereo), Master Volume |
| LFO Section | Controls | Delay, Waveshape (triangle, sawtooth, ramp, square), Rate |
| ADSR Envelope 1 | Controls | Attack, Decay, Sustain, Release |
| Modifiers Section | Controls | VCF Cutoff, VCF Emphasis, Waves Osc, Waves Sub |
| AD Envelope 3 | Controls | Attack 3, Decay 3, Env 3 Att |
| ADSR Envelope 2 | Controls | Attack, Decay, Sustain, Release |
| Modifiers Controls | Controls | ENV 1 VCF, ENV 2 Loudness, ENV 1 Waves |
| Display & Controls | Buttons | Program, Digital, Tuning, Analog, Group, Shift, Rest/Tie, Record, Stop, Play/Pause |
| Numeric Keypad | 0–9, Cursor Left, Cursor Right | |
| Digital Encoder | Data Entry Encoder (press to enter) | |
| Main Display | 2-line, 40-digit LCD display | |
| Secondary Display | 2.5 cm x 1.5 cm OLED | |
| LED | Group A / B | |
| Power Requirements | Mains Connector | Standard IEC C13 receptacle |
| Power Consumption | 20 W max | |
| Internal PSU | Switch-mode, autoranging 100–240 V (50/60 Hz) | |
| Physical | Operating Temperature | 5°C – 45°C (41°F – 113°F) |
| Dimensions (H x W x D) | 112 x 796 x 257 mm (4.41 x 31.34 x 10.12") | |
| Weight | 7.26 kg (16.0 lbs) |
