Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURESPassive stereo DI Box for general purpose applications
Custom-built Midas transformer for highest signal integrity
High headroom design offers superior sound quality
Passive design does not require any power supply
Stereo inputs on 1/4" TS connectors
Through connectors on 1/4" TS connectors
Switchable input attenuation for guitar, line and speaker levels
High quality Neutrik* XLR connectors
Earth Lift switch eliminates ground loop problems
Fully transformer-isolated design ensures electrical separation
Ultra-low noise and ultra-linear system for highest signal integrity
Aluminium extrusion casing with protective rubber corners
Compact and rugged design
DESCRIPTION
Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 20P PRO DI 2 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 20P is ideal for interfacing stereo keyboards, samplers and other electronic musical instruments to mixing consoles, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured. A passive device, the DI 20P does not require any form of external power to complete its mission. Equipped with a custom-built MIDAS transformer and switchable input Pad, DI 20P easily accommodates instruments, line, and even loudspeaker level signals – making it the perfect choice for professional audio and multimedia applications.
SPECIFICATIONS
Inputs
|
Connectors |
2 x ¼" TS unbalanced |
|
Impedance |
10 kΩ/PAD , 500 kΩ/off |
|
Max. input level |
30 dBu @ 1 kHz |
Outputs
|
Connector |
2 x XLR, balanced |
|
Impedance |
150 Ω, 1 kHz |
|
Max. output level |
8.5 dBu @ 1 kHz |
System
|
Frequency response |
20 Hz to 30 kHz (± 1 dB) |
|
THD + N (distortion) |
0.01% @ 1 kHz, 0 dBu |
|
Signal-to-noise ratio |
108 dBu |
|
Input pad |
-15 dB |
|
Power requirement |
Passive |
Physical
|
Dimensions (WxDxH) |
118 x 112 x 64 mm(4.6 x 4.4 x 2.5") |
|
Weight |
0.54 kg (1.2 lbs) |
