Klark Teknik

Klark Teknik DI 22P Passive Stereo DI Box with Midas Transformers and Extended Dynamic Range

Klark Teknik DI 22P Passive Stereo DI Box with Midas Transformers and Extended Dynamic Range

Regular price Dhs.303.00 AED
Regular price Dhs.0.00 AED Sale price Dhs.303.00 AED
Sale Sold out

Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information

KEY FEATURES
  • Passive Stereo DI Box for general purpose and multimedia applications

  • Custom-built Midas transformers for highest signal integrity

  • High headroom design offers superior sound quality

  • Passive design does not require any power supply

  • Stereo input on 1/4", 1/8" TRS and RCA connectors

  • Switchable input attenuation for guitar, line and speaker levels

  • High quality Neutrik* XLR connectors

  • Earth Lift switches for input and output eliminate ground loop problems

  • Fully transformer-isolated design ensures electrical separation

  • Ultra-low noise and ultra-linear system for highest signal integrity

  • Aluminium extrusion casing with protective rubber corners

  • Compact and rugged design


DESCRIPTION

Building on KLARK TEKNIK’s storied legacy of highest-quality direct injection devices, the DI 22P PRO DI AV 2 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DI 22P combines many of the outstanding features of the DI 20P and DI 10P direct boxes into one powerful tool that should be in every audio engineers kit. The extremely versatile DI 22P accepts dual instrument, line and speaker levels, plus also accommodates MP3, CD players, keyboard or drum submixers, and a variety of other stereo sources, and faithfully reproduces the character of electric and acoustic instruments, allowing far more of the detail of musical performances to be captured. A passive device, the DI 22P does not require any form of external power to complete its mission. Equipped with custom-built MIDAS transformers and switchable input Pads, the DI 22P is the perfect choice for premium-grade professional audio and multimedia applications.

SPECIFICATIONS

Inputs

Connectors

2 x ¼" TS, 1/8" TRS, RCA unbalanced

Impedance

30 kΩ

Max. input level

 30 dBu @ 1 kHz

Outputs

Connectors

 2 x XLR, balanced

Impedance

 600 Ω

Max. output level

8.5 dBu @ 1 kHz

System

Frequency response

20 Hz to 30 kHz (± 1 dB)

THD + N (distortion)

0.01% @ 1 kHz, 0 dBU

Signal-to-noise ratio

 105 dBu

Input pad

-15 dB

Power requirement

Passive

Physical

Dimensions (W x D x H)

 118 x 112 x 64 mm (4.6 x 4.4 x 2.5")

Weight

0.53 kg (1.2 lbs)
