Klark Teknik DS 50 Passive 1-In/5-Out Signal Splitter with Extended Dynamic Range

SKU: DS50

Log in to view price Trade pricing — AED / USD

Only 4 left
Low inventory - Hurry up!
Request Bulk Pricing

Ask an AV specialist

Video chat Chat Email +971 50 559 4871

  • Full Specifications

    Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information

    KEY FEATURES

    • Line level splitter sends single input signal to 5 outputs

    • High headroom design offers superior sound quality

    • Passive design does not require any power supply

    • High quality Neutrik* XLR connectors

    • Ultra-low noise and ultra-linear system for highest signal integrity

    • Aluminium extrusion casing with protective rubber corners

    • Compact and rugged design


    DESCRIPTION

    Building on KLARK TEKNIK�s storied legacy of highest-quality signal processing devices, the DS 50 PRO SPLITTER 5 offers the same high headroom, dynamic response and sonic clarity you have come to expect. DS 50 is ideal for routing balanced XLR signals to as many as 5 discrete destinations, including FOH and monitor consoles, active monitor loudspeakers, broadcast mixers, and more. A passive device, the DS 50 does not require any form of external power, making it the perfect solution for a wide range of professional audio and multimedia applications.

    SPECIFICATIONS

    Inputs
    Connector XLR, balanced



    Outputs

    Connectors 5 x XLR, balanced



    System

    Frequency response 20 Hz to 22 kHz (± 0.05 dB)
    THD + N (distortion) < 0.01% @ 1 kHz,+4 dBu
    Signal-to-noise ratio 121 dB
    CMRR 98 dB typical
    Insertion loss 0.05 dB @ 100 kΩ, 0.7 dB @ 600 Ω
    Power requirement Passive



    System

    Dimensions (W x D x H) 118 x 112 x 64 mm (4.6 x 4.4 x 2.5")
    Weight 0.43 kg (0.9 lbs)
