Please note: Since this is a back order product we cannot guarantee when it will be available, please also note that the price is indicative and subject to change. Please contact us for more information
KEY FEATURESStereo receiver to wirelessly stream Bluetooth* to any audio system
Perfect for hospitality and event spaces, retail and home audio, etc.
High headroom design offers superior sound quality
Maximum wireless range 100 feet (30 m)
External, articulating antenna ensures optimum transmission and reception
Aluminium extrusion casing with protective rubber corners
Floor and wall mount brackets for fixed installation (included)
High quality Neutrik* XLR and 1/4" TRS connectors
Compact and rugged design
DESCRIPTION
The AIR LINK DW 20BR Bluetooth Wireless Stereo Receiver brings the convenience of high-performance audio-streaming to any installed or portable sound system, making it ideal for hospitality and event spaces, as well as retail, home audio, and much more. Featuring a maximum wireless range of 100 feet (30 m), DW 20BR is easy to use and utilises premium-grade Neutrik balanced XLR and unbalanced 1/4" TRS connectors to cover a wide range of audio applications.
SPECIFICATIONS
Outputs
| Connectors |
Balanced XLR, unbalanced ¼" |
| Impedance |
240 Ω |
| Max. output level |
4 dBu @ 1 kHz |
Bluetooth
| Frequency range |
2402 - 2480 MHz |
| Channel number |
79 |
| Bluetooth version |
4.2 |
| Receiver range |
Up to 30 m (100 ft) |
| Output power |
Class 2, <10 dBm |
| Supported codec |
SBC, aptX |
| Supported profiles |
AVRCP 1.4, A2DP 1.2 |
System
| Frequency response |
20 Hz to 20 kHz (+0/-2 dB) |
| THD + N (distortion) |
0.1% @ 1 kHz |
| Signal-to-noise ratio |
>90 dB |
| Power adaptor |
12 V DC, 400 mA, center positive |
Physical
| Dimensions (H x W x D) | |
| Without bumpers or antenna |
54 x 108 x 103 mm (2.1 x 4.3 x 4.1") |
| With bumpers, without antenna |
63 x 118 x 112 mm (2.5 x 4.6 x 4.4") |
| With bumpers, upright antenna |
212 x 118 x 126 mm (8.3 x 4.6 x 5.0") |
| Weight incl. bumpers and antenna |
0.6 kg (1.3 lbs) |
Note: The ¼" output level is 6 dB lower than the XLR outputs Operation Ambient Temperature up to 45°C
