KEY FEATURESSingle-channel, two-band equaliser based on the classic Pultec* EQP-1A
Class A, all discrete circuitry for highest signal integrity
Premium selection 12AX7 and 12AU7 tubes
Custom-built Midas input and output transformers
Switchable frequency selectors with up to 7 frequency points
Independent boost and cut controls provide immense creative potential
Variable bandwidth control for wide sound sculpting
Inductor based equaliser section
Bypass feature allows for A/B comparison
Transformer balanced inputs and outputs on Neutrik* XLR connectors
Rugged 2U rackmount chassis for durability in portable applications
Auto-ranging universal switch-mode power supply
DESCRIPTION
If ever there is an official “Audio Technology Hall of Fame”, it will definitely include a shrine to the legendary Pultec EQP-1A. We pay homage to this audio-processing pioneer that has graced so many recordings, with our EQP-KT Classic Tube Equaliser. And while vintage Pultec units are extremely rare and expensive, the EQP-KT is amazingly affordable – and designed for the 21st Century. Mastering quality equalisation, at a price point that makes the EQP-KT equally at home in your studio – and your live rack!
SPECIFICATIONS
Audio Input
| Type |
XLR, ¼" TRS, transformer balanced |
| Impedance |
>600 Ω, balanced and unbalanced |
| Max. input level |
+21 dBu |
| Optimum input level |
+4 dBu |
Audio Output
| Type |
XLR, ¼" TRS, transformer balanced |
| Min. output load impedance |
600 Ω |
| Impedance |
<300 Ω, balanced and unbalanced |
| Max. output level |
+21 dBu |
System Specifications
| Frequency response |
20 Hz to 20 kHz, ±1 dB |
| Distortion (THD+N) |
<0.1% @ 1 kHz, +4 dBu |
| Dynamic range (20 Hz to 20 kHz unweighted) |
>101 dB, typical |
| S/N ratio |
80 dB @ +4 dBu In |
| Circuit |
Class-A |
| Vacuum tubes |
12AX7, 12AU7 |
Filters
| Low Frequency Cut / Boost Section | |
| Boost |
0 to 12 dB, shelving |
| Cut |
0 to -24 dB, shelving |
| LF boost / cut |
20, 30, 60, 100, 200 ,400, 800 Hz, selectable |
| High Frequency Boost Section | |
| Boost |
0 to +15 dB (Sharp) 0 to +10 dB (Broad) |
| HF boost |
3, 4, 5, 8, 10, 12, 16 kHz, selectable |
| Bandwidth |
Q = 1 to 10 (sharp to broad), selectable |
| High Frequency Cut Section | |
| Cut |
0 to -20 dB, shelving |
| HF cut |
3, 4, 5, 10, 20 kHz, selectable |
Power Supply
| Mains voltage |
100 – 240 V~, 50/60 Hz |
| Power consumption |
15 W |
| Fuse |
T1AH 250V |
| Mains connection |
Standard IEC receptacle |
Physical
|
Dimensions (H x W x D) |
88 x 483 x 167 mm (3.5 x 19 x 6.6") |
|
Weight |
3.0 kg (6.6 lbs) |
