Phonic

Phonic MAX 1500 Plus 900W Power Amplifier

Phonic MAX 1500 Plus 900W Power Amplifier

Regular price Dhs.1,281.00 AED
Regular price Dhs.0.00 AED Sale price Dhs.1,281.00 AED
Sale Sold out

Are you looking for a powerful, yet affordable power amplifier? Look no further than the Phonic MAX 1500 Plus 900W Power Amplifier. With 900W of power at 8 ohms for bridge mono or 150W of power at 4 ohms for stereo inputs, this power amplifier is ideal for small to medium size spaces such as schools, churches, and studios.

FEATURES:

  • Advanced powerful performance 3rd generation circuitry design
  • Output power: 450W @ 4 ohms per channel, 280W @ 8 ohms per channel
  • Front mounted gain controls
  • High continuous current output from robust toroidal transformer
  • Switchable input peak limiter and selectable high pass filter (30Hz, 50Hz) to reduce distortion and protect speakers
  • Bridge mono and parallel mode LEDs
  • Fast Recovery design for lower distortion if clipping occurs
  • Very rugged housing
  • Active balanced inputs for low noise
  • Signal level at -40, -20, -10, protect and clip LED indicators to monitor performance
  • Ground Lift switch to prevent humming
  • Selectable stereo, parallel & bridge mono amp modes
  • Two ventilation variable speed fans
  • Speakon-type connectors and 5-way binding posts speaker outputs
  • XLR & 1/4" TRS connectors for maximum input flexibility
  • Requires two standard rack units for mounting
  • Fits a standard 19" rack



SPECIFICATIONS:

Product Line Max
Manufacturer Part Number MAX1500
Product Name MAX 1500 Plus Power Amplifier
Product Model 1500 Plus
RMS Output Power 450 W
Width 482.8
Depth 415 mm
Weight Approximate 14.60 kg
Height 88.1 mm
Dimensions 88.1 mm (H): 482.8 mm (W): 415 mm (D)
Impedance 4 Ohm
Maximum Frequency Response 1 kHz
Total Harmonic Distortion THD 0.1%

HOW IT WORKS:

1. Connect your audio source to the Phonic MAX 1500 Plus Power Amplifier using XLR and/or jack inputs.

2. Set the gain controls to the desired level.

3. Connect your speakers to the Speakon-type connectors or binding posts.

4. Switch the power on and adjust the volume to the desired level.

FAQ:

Q: What type of audio sources can be connected to the Phonic MAX 1500 Plus?

A: The Phonic MAX 1500 Plus Power Amplifier can be connected to audio sources with XLR and/or jack inputs.

Q: What type of speakers can be connected to the Phonic MAX 1500 Plus?

A: The Phonic MAX 1500 Plus Power Amplifier can be connected to speakers with Speakon-type connectors or binding posts.

Q: Does the Phonic MAX 1500 Plus have any protection features?

A: Yes, the Phonic MAX 1500 Plus Power Amplifier has short circuit, thermal, subsonic, RF protection, and output DC offset for maximum protection.

View full details
