SPECIFICATIONS
General Specifications
|
Loudspeaker diameter |
394 mm / 15" |
|
Impedance |
8 Ω |
|
Continuous power rating1 |
300 W |
|
Peak power rating2 |
1200 W |
|
Sensitivity |
97 dB (±2.5 dB, 1 W / 1 m) |
|
Frequency range |
Fo ~3 kHz (-10 dB) |
|
Magnet size |
190 mm |
|
Voice coil diameter |
75.5 mm / 3" |
|
Bobbin material |
Glass fiber SV |
|
Wire type |
Copper wire |
|
Winding height |
17.8 mm |
|
Layers |
2 |
|
Cone body |
Paper |
|
Cone surround |
Cloth |
|
Item part number |
H77-00002-31677 |
Thiele & Small Parameters
|
Resonance frequency (Fs) |
46 Hz |
|
DC resistance (Re) |
6.5 Ω |
|
Mechanical Q factor (Qms) |
16.6 |
|
Electrical Q factor (Qes) |
0.49 |
|
Total Q factor (Qts) |
0.47 |
|
Mechanical moving mass (Mms) |
96.4 g |
|
Mechanical compliance (Cms) |
0.12 mm/N |
|
Force factor (Bl) |
19.3 |
|
Equivalent acoustic volume (Vas) |
130.2 I |
|
Maximum linear displacement (Xmax) |
4.9 mm |
|
Diaphragm area (Sd) |
865.7 sq cm |
|
Voice coil inductance @ 1 kHz (Le) |
1.2 mH |
Shipping Information
| Net weight | 7.1 kg (15.6 lbs) |
| Shipping weight | 10 kg (22 lbs) |
