The Diamond Studio 5-BT is an active 2-way studio monitor for desktop placement. A 5" low-frequency driver and a 1" silk soft-dome tweeter are driven by a Class D amplifier rated 140 W continuous and 280 W peak. Bluetooth is listed as Yes, alongside 1/4" jack / XLR combo and 2 x RCA inputs.
| Active or Passive | Active |
|---|---|
| System Type | Studio Monitor |
| Configuration | 2-way |
| System Continuous Power | 140 W |
| System Peak Power | 280 W |
| Max SPL @ 1m | 110 dB |
| Freq Response (+/-3 dB) | 55 Hz - 25 kHz |
| Freq Range (-10 dB) | 45 Hz - 25 kHz |
| Bi-amp Mode Switch | No |
| Bluetooth | Yes |
| IP Certification | None |
| Driver Brand | Wharfedale Pro |
| LF Driver Size | 5" |
| LF Voice Coil Size | 1" |
| LF Rated Impedance | 4 Ω |
| LF Power (RE:AES2-2012) | 50 W |
| HF Driver Type | Soft Dome Tweeter |
| HF Voice Coil Size | 1" |
| HF Diaphragm Material | Silk |
| HF Power (RE:AES2-2012) | 10 W |
| HF Rated Impedance | 4 Ω |
| Preset Library | No |
| Input Connector | 1/4” Jack / XLR Combo / 2 x RCA / BT |
| Waveguide Type | Rounded |
| Enclosure Material | MDF |
| Finish | Black Paint |
| Deployment | Desktop |
| Pole Mount | None |
| Brackets Included | No |
| Rigging | No |
| Nominal Coverage (H x V) | 135° x 110° |
| Sensitivity 2.83 V / 1 m | n/a dB |
| System Rated Impedance | n/a |
| Crossover Frequency | 2.2 kHz |
| Amplifier design | Class D |
| DSP Controls | HF / LF Level Adjust (-2, 0, +1 ,+2) |
| EQ Type | HF / LF Level Adjust (-2, 0, +1 ,+2) |
| Main Power | 100 V - 240 V |
| Power Supply | SMPS |
| Included Accessory | Quick Start Guide, AC cable |
| Unpacked - Height (mm) | 290 |
|---|---|
| Unpacked - Width Front (mm) | 180 |
| Unpacked - Width Rear (mm) | 180 |
| Unpacked - Depth (mm) | 240 |
| Packed - Height (mm) | 405 |
| Packed - Width Front (mm) | 260 |
| Packed - Width Rear (mm) | 260 |
| Packed - Depth (mm) | 320 |
| Weight - Nett (kg) | 5.1 |
| Weight - Gross (kg) | 6.3 |
Yes. Bluetooth is listed as Yes, and BT appears in the input connector list.
The DSP controls row lists HF / LF level adjust (-2, 0, +1, +2).
The included accessories are a Quick Start Guide and an AC cable.
