| System Type | 2 x 5″ Passive |
| Configuration | Two-way |
| Frequency Response (+/-3 dB) | 70 Hz – 20 KHz |
| Frequency Range (- 10 dB) | 65 Hz – 20 KHz |
| Sensitivity (2.83v/1m) | 94 dB |
| Calculated Maximum SPL @1 m | 120 dB |
| System Rated Impedance | 8 Ω |
| Low Frequency Transducer | |
| Size | 2 x 127 mm / 2 x 5″ |
| Voice Coil Size | 25.5 mm / 1″ |
| Rated Impedance | 8 Ω |
| LF Power (re:AES2-2012) | 2 x 50 W |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Voice Coil Size | 25.4 mm / 1″ |
| Exit Size | 25.4 mm / 1″ |
| Diaphragm Material | Rugged Phenolic |
| Rated Impedance | 8 Ω |
| HF Power (re:AES2-2012) | 20 W |
| Nominal Coverage (H x V) | 90˚x 60˚ |
| Power | |
| System Continuous Power | 100 W |
| System Programme Power | 200 W |
| System Peak Power | 400 W |
| Crossover frequency | 2.0 KHz |
| Sample | Sample |
