Wharfedale Pro WDGA12 Speaker Monitor Active 1x12"

SKU: WDGA12

Log in to view price Trade pricing — AED / USD

In stock
Request Bulk Pricing

Ask an AV specialist

Video chat Chat Email +971 50 559 4871

  • Full Specifications

    Download Product Data Sheet

    KEY FEATURES

    • Versatile floor monitors….with more
    • Coaxial design
    • Deploy as 25° or 60°
    • Spherical waveguides
    • Optional WPB-W12/ 15 U-Brackets and WPB-7 for easy wall mounting
    • Active models with 8 x presets inc FIR plus PRO=LINK software control
    • Durable Tough-Tone paint finish. Put your boot on it!!

      SPECIFICATIONS

      System Type
      12″ coaxial Active
      Configuration Two-way
      Frequency Response (+/-3 dB)
      58 Hz – 20 KHz
      Frequency Range (- 10 dB)
      40 Hz – 25 KHz
      Sensitivity 2.83 V/1 m 98 dB
      Calculated Maximum SPL @1 m 127 dB
      System Peak SPL* 133 dB
      *level at 1 m using pink noise with crest factor 4, with dedicated preset.
      LF Size 12”
      LF Voice Coil Size 2.5”
      LF Frame Material Aluminium
      HF Driver Type
      Compression Driver
      Voice Coil Size 2.0”
      Exit Size 1.0”
      Waveguide Type Spherical
      Nominal Coverage (H x V) 70°
      Driver brand
      Wharfedale Pro
      Amplifiers
      Amplifier Design Class D
      Power Rating:
      800 W Peak (700 W LF + 100 W HF),
      400 W Continuous (350 W LF + 50 W HF)
      Thermal Protection
      Amplifier Shut Down. Auto Reset
      Low Line Voltage Shut Down
      60% Nominal Line Voltage
      Driver Protection
      Independent LF/ HF RMS and Peak Limiters
      DC and Short Protection Yes
      Clip Limiter Yes
      Limiter Indicator Red LED
      Signal Indicator Green LED
      Power/Active Indicator White LED
      Find Function Indicator Blue LED
      Input Impedance
      Balanced:10 KΩ
      AC Power details – Power Supply
      AC 100-120 V~ and 220-240 V~, 50/60 Hz Automatic
      Input
      Balanced socket XLR
      Link
      Balanced pin XLR
      AC Power
      AC Output: powerCON
      AC Input: powerCON
      Rigging & Hardware:
      35 mm Pole-mount
      4 x M8 threaded points for WPB-7 or PowerdriveTM Series 100 products
      Optional Accessories
      WDG-W12 horizontal flying yoke
      Heavy-duty transport soft cover
      Handle 1 on top
      Cabinet Type Trapezoid
      Enclosure Material and finish
      15 mm plywood
      Tough-Tone
      Colour Options
      Black paint, White on request
      Grille Material & Finish
      Powder coated steel
      Monitor Angle (degrees) 60° – 25°
